Field Work Gallery
Real low-voltage, network infrastructure, wireless, and smart hands work performed across commercial and field service environments in West Texas and beyond.
- Commercial network infrastructure
- Structured cabling, rack, and smart hands support
- Wireless, camera pathway, and site survey field work
Photos are selected and reviewed to avoid exposing sensitive customer systems, credentials, live camera feeds, or private network details.
Nova Titan Systems supports commercial, retail, healthcare, restaurant, industrial, and public-sector environments with field-ready low-voltage, IT infrastructure, and documentation-focused service.
Commercial Warehouse Infrastructure
Low-voltage and communications pathway work inside a large commercial facility
Large Commercial Facility Buildout
Cabling pathways, communications, and network infrastructure prep for a large commercial site
Enterprise Wireless Access Point
Commercial wireless access point installation for structured Wi-Fi coverage
Network Rack Installation
Commercial network rack and structured cabling installation
Wireless Site Survey
Rooftop wireless equipment staging during a commercial connectivity site survey
Rooftop Wireless Mount
Rooftop wireless internet mount installation for a commercial property
Commercial Site Survey
Exterior site survey for structured cabling and network infrastructure planning
Rack Staging
Network rack staged before commercial equipment installation
Structured Cabling & Patch Panels
Cat6 patching, cable management, and low-voltage infrastructure work.
Cat6 Patch Panel Rack
Organized blue Cat6 structured cabling with clean commercial patching
Network Rack with Carrier Demarc
AT&T demarc, bandwidth management, firewall, switching, and patching in one rack
Fortinet Rack & Patch Panel
Fortinet firewall, FortiSwitch, and rack-mounted patch panel support
Cable Pathway Routing
Low-voltage cable bundle through a commercial wall pathway
Fortinet Firewall & Security Appliances
FortiGate firewall deployments, FortiSwitch installations, and security rack builds.
FortiGate 40F Firewall
Fortinet FortiGate 40F deployed in a commercial rack environment
Fortinet + UPS Rack
FortiGate firewall, FortiSwitch, and Eaton UPS in a commercial rack
Fortinet + Cisco Rack
Fortinet firewall and Cisco router deployed together for commercial network support
Server Rooms & MDF Environments
Dell server deployments, MDF rack work, power distribution, and telecom rack support.
Dell Server & Storage Rack
Dell server/storage rack with PDU hardware and cabling support
Full Dell Server Rack (After)
Completed Dell server rack with power distribution after field support work
Server Room / MDF Entry
Server room and MDF area for commercial network infrastructure support
MDF / BAS Rack & Conduit
Complex MDF and building automation rack with conduit and pathway support
Telecom Rack & Power Distribution
Power distribution and Cisco telecom rack support with structured cabling
Wireless Infrastructure & Access Points
Fortinet wireless AP installs, Starlink rooftop mounts, and exterior wireless work.
Fortinet AP Ceiling Mount
Fortinet wireless access point ceiling installation for commercial Wi-Fi coverage
Starlink Rooftop Dish Mount
Starlink Gen 3 flat-panel dish on a commercial ballast roof mount
Starlink Mount — Aerial View
Overhead view of Starlink installation on a commercial rooftop
Starlink Parapet / Eave Mount
Starlink dish on a brick exterior eave mount for commercial wireless service
Rooftop Camera / Wireless Mount
Exterior rooftop mount with cabling support for wireless or camera infrastructure
Audio / AV + Network Integration
Combined audio amplifier, firewall, switching, and power distribution in a single rack build.
Labeled Rack Power & Network
Labeled PDU with modem, FortiGate, FortiSwitch, and amplifier circuit connections
AV + Network Rack Integration
Fortinet equipment and Crown amplifier in a combined audio/network rack build
Fiber & ONT Support
Fiber ONT wall mount and carrier termination support.
Fiber ONT Wall Mount
Clean fiber ONT and modem wall mount with fiber drop for commercial connectivity
Nova Titan Systems supports commercial, retail, healthcare, restaurant, industrial, and public-sector environments with field-ready low-voltage, IT infrastructure, and documentation-focused service across West Texas, Houston, and DFW.
